Measuring Tube Material: SS316L, Hastelloy C

Pressure: 1.6, 2.5, 4.0, 6.3, 10 MPa; 16 MPa(Applicable for ≤DN100); 25 MPa(Applicable for ≤DN50)

Medium Temperature: Compact Type -50…+125°C; Remote Type -50…+200°C; High Temperature Type -50…+350°C; Low Temperature Type -200…+125°C

Ambient Temperature: -40…+55°C

Accuracy: ±0.1%, ±0.2%, ±0.5%

Output: 4-20mA; Pulse

Communication: RS485; HART

Explosion Proof: EX db ib IIB / IIC T*Gb

Protective: IP67
